GPIO0 and GPIO1 share pin with DMIC-CLK and DMIC-DATA Up to two GPIOs (General Purpose Input and Output) for customized applications.Supports legacy analog mixer architecture.Three jack detection pins each designed to detect up to 4 jacks.Up to four channels of microphone array input are supported for AEC/BF applications.

Acoustic echo cancellation headphone software#

Software selectable 2.5V/3.2V/4.0V VREFOUT.

Acoustic echo cancellation headphone generator#

Supports external PCBEEP input and built-in digital BEEP generator.

High-quality analog differential CD input.

Port-B/C/E/F with software selectable boost gain (+10/+20/+30dB) for analog microphone input.

Port-D/E/F built-in headphone amplifiers.

All analog jacks (port-A to port-G) are stereo input and output re-tasking.

All ADCs supports 44.1k/48k/96k/192kHz sample rate.

All DACs supports 44.1k/48k/96k/192kHz sample rate.

Two stereo ADCs support 16/20/24-bit PCM format, multiple stereo recording.

Acoustic echo cancellation headphone plus#

Ten DAC channels support 16/20/24-bit PCM format for 7.1 channel sound playback, plus 2 channels of concurrent independent stereo sound output (multiple streaming) through the front panel output.

DACs with 95dB SNR (A-weighting), ADCs with 90dB SNR (A-weighting).

Acoustic echo cancellation headphone Pc#

With various software utilities like environment sound emulation, multiple-band and independent software equalizer, dynamic range compressor and expander, optional Dolby PCEE program, SRS TruSurround HD, SRS Premium Sound, Fortemedia SAM, Creative Host Audio, Synopsys Sonic Focus, DTS Surround Sensation | UltraPC, and DTS Connect licenses, the ALC892 offers the highest sound quality, providing an excellent entertainment package and game experience for PC users. The ALC892 supports host audio from the Intel chipsets, and also from any other HDA compatible audio controller. The ALC892 also features secondary SPDIF-OUT output and converter to transport digital audio output to a High Definition Media Interface (HDMI) transmitter. Support for 16/20/24-bit SPDIF input and output with up to 192kHz sample rate offers easy connection of PCs to consumer electronic products such as digital decoders and speakers. All analog I/Os can be re-tasked according to user definitions. Two stereo ADCs and one stereo digital microphone converter are integrated and can support a microphone array with Acoustic Echo Cancellation (AEC), Beam Forming (BF), and Noise Suppression (NS) technologies.Īll analog I/O are input and output capable, and headphone amplifiers are also integrated at three analog output ports (port-D/port-E/port-F). The ALC892 provides ten DAC channels that simultaneously support 7.1 channel sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. The ALC892-CG/ALC892-DTS-CG is a high-performance multi-channel High Definition Audio Codec with Realtek proprietary lossless content protection technology that protects pre-recorded content while still allowing full-rate audio enjoyment from DVD audio, Blu-ray DVD, or HD DVD discs. This type of echo appears when an electric signal from the data transmission line interferes with the data reception line.

As a result, the given audio signal does not contain echoes anymore and can be transmitted further.

The signal from the near side is subtracted from the filtered distant signal.

At the same time, the signal received from a distant room is being filtered and delayed in order to look like the same signal, that got into a microphone at the nearest room.

The signal is received by a microphone at the nearest room.

The nearest speaker reproduces this signal.

The following suppression algorithm is applied to eliminate acoustic echo:

Reflection from the elements surrounding a device.

Mechanical connection between a microphone and a speaker.

There are two types of regenerative coupling: That happens when the sound from the handsfree speaker enters the microphone in the same room. The acoustic echo appears due to regenerative coupling.

There are two types of echo: acoustic and electric (hybrid). This process is carried out with the help of echo suppressors and echo cancellers.

Echo Cancellation is the process of removing echo from transmitted audio signals.
